EDGE-CORE NETWORKS: MLTG-360 TERRAGRAPH
Standard :
• 802.11ay
60GHz Radio:
• 4 x antenna tiles per radio
• 64 antenna elements for each antenna tile
• 90 degrees azimuth scan range: -45º to 45º
• 50 degrees elevation scan range: -25º to 25º
RF Output Power:
• Up to 43 dBm
Frequency Band:
• 57-66GHz
Modulation:
• BPSK
• QPSK
• 16QAM
MLTG-360 is a TerragraphTM-certified distribution node (DN). MLTG-360 has four radios, supporting 360o coverage. Each radio of MLTG-360 is equipped with a 256-element beamforming phased array antenna, supporting up to 3.8 Gbps aggregate throughput. In addition, MLTG-360 supports advanced mesh solutions to establish a robust wireless network. Resilient mesh can be easily constructed between multiple MLTG-360 to construct the wireless network with high availability. MLTG-360 provides fiber-like connectivity at a lower cost than fiber, ideal for fixed wireless access, backhaul for Wi-Fi, or cellular networks.
EDGE-CORE NETWORKS: MLTG-CN LONG RANGE (LR)
Standards:
• 802.11ay
RF Output Power:
• Up to 56 dBm
Frequency Band:
• 57-66GHz (channel 1 to channel 4)
Channel Bandwidth:
• 2160MHz
• 4320MHz (available in future software release)
Modulation:
• BPSK
• QPSK
• 16QAM
MLTG-CN LR is a Terragraph-certified client node (CN). MLTG-CN LR supports IEEE802.11ay standard to deliver high-speed Internet in a noise-free and unlicensed 60GHz spectrum. With high-gain antenna and beamforming technology, MLTG-CN LR is suitable for long-range deployments. The range can reach up to 1 km when paired with MLTG-CN LR. And it can reach up to 700 meters when paired with MLTG-360. MLTG-CN LR can be paired to quickly build long-range Point-to-Point (PtP) links for the backhaul or last-mile access and deliver fiber-like multi-gigabit throughput. When connected with MLTG-360, MLTG-CN LR can also function as an endpoint to provide last-mile wireless gigabit connectivity to the client site, such as a warehouse, company building, or residential area.
EDGE-CORE NETWORKS: MLTG-CN (Short Range)
Standards:
• 802.11ay
60GHz Radio:
• Phased array antenna with 64 antenna elements
• 90 degrees azimuth scan range: -45º to 45º
• 50 degrees elevation scan range: -25º to 25º
RF Output Power:
• Up to 38 dBm
Frequency Band:
• 57-66GHz
Modulation:
• BPSK
• QPSK
• 16QAM
MLTG-CN is a TerragraphTM-certified client node (CN). MLTG-CN supports IEEE802.11ay standard to deliver high-speed Internet in a noise-free and unlicensed 60GHz spectrum. When connected with a TerragraphTM-certified distribution node (DN), MLTG-CN can function as Customer Premise Equipment (CPE) to provide last-mile wireless gigabit connectivity to the client site, such as a warehouse, company building or residential area. MLTG-CN can also be paired to deliver Point-to-Point (PtP) wireless gigabit throughput for backhaul or last-mile access without the costly installation of cabled fiber.
OpenWIFI Products
EDGE-CORE NETWORKS: SPARK AC Wave2
This new access point from IgniteNet is powered by a next-generation quad-core CPU, which allows super-high performance when serving many users. 802.11ac wave2 standard support has MU-MiMo compatibility allowing the AP to transmit data more efficiently and at higher speeds. Dual radio design with two spatial streams per radio enabled lightning-fast speeds up to 1.3 Gbps total capacity.
Note: LTE Dongle Supported
EDGE-CORE NETWORKS: SUNSPOT AC Wave2
IgniteNet™’s SunSpot™ AC Wave2 is a powerful, cloud-managed 802.11ac Wave2 access point supporting up to 2.6 Gbps data rate over the air. The SunSpot™ AC Wave2 contains two independent 4 x 4 MiMo, concurrent operation radios – one 802.11ac (5GHz) radio and one 802.11n (2.4GHz) radio – capable of delivering blisteringly fast wireless speeds. The universal design of the SunSpot™ AC Wave2 allows it to be placed inconspicuously in both indoor and outdoor environments due to its innovative IP-55 standards-rated enclosure, bringing fast wireless connections to hard-to-reach locations. The advantages of 802.11ac wave2 standards like MU-MiMo and hardware-based radio acceleration make this access point ideal for high-density deployments and high throughput applications.
EDGE-CORE NETWORKS: SparkAC Wave2 Mini PoE (Palm Size)
IgniteNet™’s Spark™ AC Wave2 Mini PoE is one of the market's most cost-effective, covert, cloud-managed 802.11ac Wave2 access points. The Spark™ AC Wave2 Mini PoE contains two independent, concurrent operation radios - one 802.11ac (5GHz) radio and one 802.11n (2.4GHz) radio - capable of delivering fast wireless speeds. The sleek design of the Spark™ AC Wave2 mini PoE allows it to be placed inconspicuously in both offices and homes, bringing fast wireless connections to hard-to-reach locations. The Spark Wave2 mini PoE is the latest version of the highly popular Spark Wave2 mini with similar specs. However, it includes two Gigabit Ethernet ports (vs. a single 1G port + 100M port) and adds 802.3af PoE powering (vs. DC jack input), which allows powering it with PoE switches.
EDGE-CORE NETWORKS: SparkAC Wave2 Mini (No PoE) (Palm Size)
IgniteNet™’s Spark™ AC Wave2 Mini is the market's most cost-effective, covert, cloud-managed 802.11ac Wave2 access point. The Spark™ AC Wave2 Mini contains two independent, concurrent operation radios - one 802.11ac (5GHz) radio and one 802.11n (2.4GHz) radio - capable of delivering fast wireless speeds. The sleek design of the Spark™ AC Wave2 allows it to be placed inconspicuously in both offices and homes, bringing fast wireless connections to hard-to-reach locations.
.png)
ecCloud MANAGED SWITCHES
ECS1100-5P POE+
The ECS1100-5P is a fanless design PoE switch that supports up to 4 ports at 30 W to meet the increasing power demands of users. The ECS1100 Series offers complete PoE solutions from 120 W to 250 W. All the switches are rack mountable.
Smart Managed Access Switch
-
1 x RJ-45 10/100/1000 Uplink Port
-
4 x RJ-45 PoE Ports
-
af/at 120W
-
10 Gbps Switching Capacity
-
Support ecCLOUD
Download Specification/Datasheet
ECS1100-10HP POE+
The ECS1100-10HP supports 802.3bt PoE Type4 with Power Class 8, which means its maximum power from PSE to PD is up to 90W. The ECS1100-10HP also delivers a default 250 W of PoE power to support future IP cameras, IP video telephones, access points, and PoE computers.
Smart Managed Access Switch
-
8 x RJ-45 10/100/1000 Ports (PoE)
-
af/at/bt 250W
-
2 x 1G SFP Port
-
20 Gbps Switching Capacity
-
Support ecCLOUD
Download Specification/Datasheet
ECS2100-10PE POE+
ECS2100-10PE is a Web Smart Pro Switch, it supports 8 x GE PoE+ ports + 2 GE SFP uplink ports with 1 RJ45 Console port and Fanless design. The PoE Budget is max.65W.
L2+/L3 Lite Managed Access Switch
-
8 x 1GbE (PoE)
-
af/at 65W
-
2 x 1G SFP
-
20 Gps Switching Capacity
Download Specification/Datasheet
ECS2100-10P POE+
ECS2100-10P is an L2/L2+ Gigabit Ethernet Managed PoE Switch, it supports 8 x GE PoE ports + 2 GE SFP uplink ports with 1 RJ45 Console port and Fanless design. The PoE budget max. 125W.
L2+/L3 Lite Managed Access Switch
-
8 x 1GbE (PoE)
-
af/at 125W
-
2 x 1G SFP
-
20 Gbps Switching Capacity
-
Support ecCLOUD
Download Specification/Datasheet
ECS2100-28P POE+
The ECS2100-28P is an L2/L2+ Gigabit Ethernet Managed PoE Switch, it supports 24 x GE PoE+ ports and 4 x 1G SFP ports. The PoE Budget is max.200W. ECS2100-28P provides up to 30 Watts of power to attached devices, such as VoIP phones, wireless access points, and surveillance cameras, all over existing Ethernet cables.
L2+/L3 Lite Managed Access Switch
-
24 x 1GbE (PoE)
-
af/at 200W
-
4 x 1G SFP
-
56 Gbps Switching Capacity
-
Support ecCLOUD
Download Specification/Datasheet
ECS2100-28PP POE+
The ECS2100-28PP an L2/L2+ Gigabit Ethernet Managed PoE Switch, it delivers a default 370 W of PoE power to support future IP cameras, IP telephones, or access points.
L2+/L3 Lite Managed Access Switch
-
24 x 1GbE (PoE)
-
af/at 370W
-
4 x 1G SFP
-
56 Gbps Switching Capacity
-
Support ecCLOUD
Download Specification/Datasheet
ECS4100-28P POE+
The ECS4100-28P switch is a 24-port PoE Gigabit Ethernet access switch with 4 x 1G uplink SFP ports. The switch is ideal for Internet Service Providers (ISPs) and Multiple System Operators (MSOs) to provide home users with triple-play services and up to a Gigabit bandwidth.
L2+/L3 Lite Gigabit Ethernet Access Switch
-
24 x 1GbE (PoE)
-
af/at 190W
-
4 x 1G SFP
-
56 Gbps Switching Capacity
-
Support ecCLOUD
Download Specification/Datasheet
ECS4100-52P POE+
The ECS4100-52P switch is a 48-port PoE Gigabit Ethernet access switch with 4 x 100M/1G uplink SFP ports. The switch is ideal for Internet Service Providers (ISPs) and Multiple System Operators (MSOs) to provide home users with triple-play services and up to a Gigabit of bandwidth.
L2+/L3 Lite Gigabit Ethernet Access PoE Switch
-
48 x 1GbE (PoE)
-
af/at 370W
-
4 x 1G SFP
-
104 Switching Capacity
-
Support ecCLOUD
-
Download Specification/Datasheet
ECS5520-18T
The ECS5520 series consists of two switches with sixteen 10GbE SFP+ ports or 10GBASE-T ports and two 40GbE uplink ports. The switches are designed for carrier/enterprise aggregation or small data center top-of-rack. The ECS5520 series is an ideal solution for traditional three-tier aggregation or core topologies and folded-Clos architectures, serving with a 2:1 oversubscription. The ECS5520 switches are packed with features that bring high availability, comprehensive security, robust multicast control, and advance QoS to network aggregation, while maintaining simple management. The switch also supports the most advance IPv6 management, IPv6 security, and IPv6 multicast control in accordance with the growth of IPv6 deployment. ISPs can expand their services from home to business users by providing a more reliable and resilient network (ITU-T G.8032 ERPS), L2 VPNs, and advanced OAM (Operations, Administration, and Maintenance) functions to ensure service-level agreements.
L2+/L3 Lite 10G Ethernet Aggregation Switch with 2x40G Uplinks
-
16 x 10G
-
2 x 40G QSFP+
-
1 x Console Port
-
1 x USB Port
-
480 Gbps Switching Capacity
-
Support ecCLOUD
Download Specification/Datasheet
ECS5520-18X
The ECS5520 series consists of two switches with sixteen 10GbE SFP+ ports or 10GBASE-T ports and two 40GbE uplink ports. The switches are designed for carrier/enterprise aggregation or small data center top-of-rack. The ECS5520 series is an ideal solution for traditional three-tier aggregation or core topologies and folded-Clos architectures, serving with a 2:1 oversubscription. The ECS5520 switches are packed with features that bring high availability, comprehensive security, robust multicast control, and advance QoS to network aggregation, while maintaining simple management. The switch also supports the most advance IPv6 management, IPv6 security, and IPv6 multicast control in accordance with the growth of IPv6 deployment. ISPs can expand their services from home to business users by providing a more reliable and resilient network (ITU-T G.8032 ERPS), L2 VPNs, and advanced OAM (Operations, Administration, and Maintenance) functions to ensure service-level agreements.
L2+/L3 Lite 10G Ethernet Aggregation Switch with 2x40G Uplinks
-
16 x 10G SFP+
-
2 x 40G QSFP+
-
1 x Console Port
-
1 x USB Port
-
480 Gbps Switching Capacity
-
Support ecCLOUD
Download Specification/Datasheet
ECS4125-10P POE++
The Edgecore ECS4125-10P switch is a 2.5 Gigabit Ethernet access switch with two 10G uplink ports. The switch is an ideal 2.5 Gigabit PoE access switch for SMB, enterprise, and campus networks. The ECS4125-10P switch has features that bring high availability, comprehensive security, robust multicast control, and advanced QoS to the network edge while maintaining simple management. The switch also supports the most advanced IPv6 management, IPv6 security, and IPv6 multicast control following the growth of IPv6 deployment.
L2+/L3 Lite 2.5G Ultra PoE++ Switch
-
8 x 1G/2.5G RJ45 Ports (PoE)
-
af/at/bt 240W
-
2 x 10G SFP+ Uplink Ports
-
1 x Console Port
-
80G Switching Capacity
-
Support ecCLOUD
